Copper Insulated Conductor / Bare / Hard Drawn / PVC / 32 mm² / Ø 9.2 mm / 7

Copper Insulated Conductor / Bare / Hard Drawn / PVC / 32 mm² / Ø 9.2 mm / 7

€8,66 (EXW)

2077111 Category: Tags: ,
Delivery time: 4 Week(s)

Loading...

Description

 Country of origin  Hungary
 Rated current  190 A
 Conductor resistance  0.5497 Ω / km
 Conductor cross-section S  32.00 mm²
 Conductor diameter S  9.20 mm
 Conductor diameter T  2.46 mm
 Sheath thickness  0.80 mm
 Failing load  12.40 kN
 Number of cores  7
 Type  8
 Type  Bare
 Type  Hard drawn
 Conductor material  Copper
 Outer sheath material  Polyvinyl chloride PVC
 Temperature  -25 …+80 °C
 Weight  335.00 kg / km
 Standard  BS 7884:1997

Additional information

Weight 4 kg
